No mode conditioning patch cord is required for applications over OM3 or OM4.
To make sure that specifications are met over FDDI-grade, OM1 and OM2 fibers, the transmitter should be coupled through a mode conditioning patch cord. The Cisco 10GBASE-LRM Module supports link lengths of 220m on standard Fiber Distributed Data Interface (FDDI) grade Multimode Fiber (MMF). * Except for version 1, which supports only 10GBASE-SR. Using 4700MHz *km MMF (OM4), up to 400m link lengths are possible. Using 2000MHz *km MMF (OM3), up to 300m link lengths are possible. It supports a link length of 26m on standard Fiber Distributed Data Interface (FDDI)-grade Multimode Fiber (MMF). The Cisco SFP-10G-SR-X is a multirate * 10GBASE-SR, 10GBASE-SW and OTU2/OTU2e module for extended operating temperature range. The Cisco 10GBASE-SR Module supports a link length of 26m on standard Fiber Distributed Data Interface (FDDI)-grade Multimode Fiber (MMF). Using 4700 MHz *km MMF (OM4), up to 400 meter link lengths are possible. Using 2000 MHz *km MMF (OM3), up to 300-meter link lengths are possible. The Cisco 10GBASE-SR module supports a link length of 26 meters on standard Fiber Distributed Data Interface (FDDI)-grade Multimode Fiber (MMF). They are suitable for distances up to 30 meters and offers a cost-effective way to connect within racks and across adjacent racks. It has the SFP+ form factor and an RJ-45 interface so that CAT5e/CAT6A/CAT7 cables can be used to connect to end points with embedded 10GBASE-T ports. The Cisco 10GBASE-T module (Figure 2) offers connectivity options at the following data rates: 100M/1G/10Gbps. Cisco quality Identification (ID) feature enables a Cisco platform to identify whether the module is certified and tested by Cisco.Optical interoperability with 10GBASE XENPAK, 10GBASE X2, and 10GBASE XFP interfaces on the same link.Digital optical monitoring capability for strong diagnostic capabilities.Supports “pay-as-you-populate” model for investment protection and ease of technology migration.Hot-swappable input/output device that plugs into an Ethernet SFP+ port of a Cisco switch (no need to power down if installing or replacing).Industry’s smallest 10G form factor for greatest density per chassis.Cisco SFP+ modules offer the following features and benefits.
